Features:
- Selection of mode in touch screen panel
- Absolutely noiseless operation.
- Programmable system
- Removable tray
Technical Specification:
| Model | 1855.DNEU.01 |
| Material of construction | MS with powder coated finish |
| Type of motion | Reciprocal shaking motion |
| SPM range | 50 to 150 Strokes per minute |
| Movement | Linear mechanical guided drive |
| Movement sensor | IR scan sensor |
| Motor | Stepper servo motor (Brushless) |
| Drive | Servo drive |
| Display | 4.3” Touch screen TFT LCD display |
| Setting of Parameters | Touch sensitive membrane |
| LED Indication | Indication of Power, Heater |
| Temperature process controller | Microprocessor based PID Temperature controller with Touch Panel |
| Temperature range | 5 Degree above ambient to 100 Degree |
| Temperature accuracy | +/- 0.5Degree |
| Temperature sensor | Pt 100 |
| No of program | 5 program, 5 steps for both shaker and water bath |
| Programmable Parameters | SPM, Temperature and Time |
| Heater | Immersion Heater |
| Heater power | 1500 W |
| Water tank | Stainless steel |
| Tank capacity | 15 litres |
| Tray | Stainless steel Removable Tray |
| Tray capacity | 250ml clamp-9 nos |
| Hood | Stainless steel cover |
| Internal Recirculation pump for Temperature stability | Magnetic pump |
| External recirculation pump | (optional) magnetic pump |
| Electrical requirement | 230V/50Hz/6A |
| Unit dimension | 25 x 25 x15inches |
