• Aluminium Moulded Construction
  • Easy temperature & Stir controls
  • Installed with Safety PT sensor for fail safe operation.
  • Hot top indicator for temperatures above 50°C.
  • Large top plate to assist beakers upto 2000 ml.
  • High magnetic strength.
  • Electronic variable speed control with Knob for display.
  • Knob for regulating variable temperature.
  • Heat reach Indicator, To ensure you correct temperature of plate surface.
  • Stirring & temperature indicator
  • Error indicators for heat & Stir function inbuilt trouble shoot
  • Hot top warning indicator for temperature >50°C

Technical Specification:

Heang Mantle Material : Stainless Steel 304 Grade/ Ceramic Coated
Dimension of heang plate : 150 Ø
Speed range : 50-1600 RPM
Maximum srring bar Length : Can use upto 80 mm bar (at lower speed)
Temperature Range : Ambient to 350°C approx
Dimensions of hot plate body : 273x160x102mm
Weight of body : 2.8 kgs
Permissible ambient Temperature : 5- 40 °C
Permissible relave moisture : 80%
IP Class : 22
Also Known as : 900.DG.01

Included Accessory:

Cat. No. Accessories
850.800.02 Magnetic Stirring bar 35 mm x 9 mm






Temp Control RPM Plate Size Vessel Capacity Plate Material
Variable upto 350° C 1600 RPM 150mmØ upto 2L Beakers SS 304 Grade
